CY39000(SASPF200)型 带冲压圆形座顶丝外球面球轴承参数表
| 带座轴承型号 |
外形尺寸 |
带座轴承重量 |
配用轴
承代号 |
配用轴承
座代号 |
螺栓
尺寸 |
配合
轴径 |
| D |
B1 |
S |
J |
H |
A |
A1 |
N |
Kg |
| CY390203 |
40 |
28.6 |
6.5 |
63.5 |
80 |
15 |
4 |
7.1 |
0.28 |
390203 |
CY203 |
PF203 |
M6 |
17 |
| CY390204 |
47 |
31 |
7.5 |
71.5 |
90 |
17 |
4 |
9 |
0.37 |
390204 |
CY204 |
PF204 |
M8 |
20 |
| CY390205 |
52 |
31 |
7.5 |
76 |
95 |
17 |
4 |
9 |
0.42 |
390205 |
CY205 |
PF205 |
M8 |
25 |
| CY390206 |
62 |
35.7 |
9.0 |
90.5 |
112 |
19 |
5 |
11 |
0.65 |
390206 |
CY206 |
PF206 |
M10 |
30 |
| CY390207 |
72 |
38.9 |
9.5 |
100 |
122 |
21 |
5 |
11 |
0.80 |
390207 |
CY207 |
PF207 |
M10 |
35 |
| CY390208 |
80 |
43.7 |
11 |
119 |
148 |
21 |
7 |
13 |
1.36 |
390208 |
CY208 |
PF208 |
M12 |
|
| CY390209 |
85 |
43.7 |
11 |
120.5 |
149 |
22 |
7 |
13 |
1.14 |
390209 |
CY209 |
PF209 |
M12 |
|
| CY309210 |
90 |
43.7 |
11 |
127 |
156 |
22 |
8 |
13 |
1.68 |
390210 |
CY210 |
PF210 |
M12 |
|
| CY390211 |
100 |
48.4 |
12 |
138 |
167 |
25 |
8 |
13 |
1.83 |
390211 |
PF211 |
PF211 |
M12 |
|
| CY390212 |
110 |
53.1 |
13.5 |
148 |
176 |
24 |
8 |
13 |
2.54 |
390212 |
CY212 |
PF212 |
M12 |
|
|
|
